IoT in Manufacturing: The Ultimate Guide

Chief Technology Officer, ScienceSoft

Published:

Stronger demand for customization, increasing customer expectations, the complexity of the global supply chain – these and many other challenges encourage manufacturers to find new, more innovative ways to remain competitive. In an attempt to gain productivity improvements and uncover new ways of enhancing manufacturing and supply chain operations, businesses resort to digital transformation. CGI’s study reports that 62% of surveyed enterprises are already executing digital transformation pilots and programs.

Industrial Internet of Things (IIoT) is a way to digital transformation in manufacturing. Industrial IoT employs a network of sensors to collect critical production data and uses cloud software to turn this data into valuable insights about the efficiency of the manufacturing operations.

IoT in manufacturing

Drivers for IIoT adoption in Manufacturing

Bsquare annual IIoT maturity survey (2017) reports that 86% of respondents have already adopted IIoT solutions, 84% of them finding IIoT extremely effective. The survey validates that IIoT adoption is progressing as more manufacturing enterprises shift to advanced IIoT applications featuring analytics and automation. The adoption drivers for the Industrial IoT solutions include:

  • Cost reduction. Due to optimized asset and inventory management (hence, lower inventory carrying costs and search times), reduced machine downtime, more agile operations, and more efficient energy use, companies reduce operational costs and even create new sources of revenue (for instance, smart, connected products allow to shift from selling products to selling experience – product usage and post-sale services). McKinsey estimates that IoT applications in manufacturing are expected to generate $1.2 to $3.7 trillion of economic value annually by 2025.
  • Shorter time-to-market. Faster and more efficient manufacturing and supply chain operations allow to significantly reduce product cycle time. Harley-Davidson, for instance, leveraged IoT to reconfigure its York, PA manufacturing facility and reduce the time it takes to produce a motorbike from a 21-day cycle to six hours.
  • Mass customization. Mass customization allows businesses to create products tailored to the needs of a particular purchaser, while retaining high production volumes. The manufacturing process behind that requires a dramatic increase in the variety of produced SKUs. The increase in the number of SKUs (each requiring different materials and components) causes inventory to go up and become more diverse. At the same time, manufacturing operations get more complex: the production of, say, 20 items of SKU X can be immediately followed by the production of 10 items of SKU Y. It makes monitoring the effectiveness of manufacturing operations and the location of inventory items burdensome and, in some cases, not feasible. IIoT facilitates mass customization by becoming a source of real-time data required for thoughtful forecasting, shop floor scheduling and routing.
  • Improved safety. IIoT helps to ensure a safer workplace. Paired with wearable devices, IIoT allows monitoring workers’ health state and risky activities that can lead to injuries. Along with ensuring workers’ safety, IIoT addresses safety problems in potentially hazardous environments. For instance, in oil and gas industry, IIoT is applied to monitor gas leakages as it travels through the pipe network.

Three dimensions of IIoT’s impact

IoT technologies are transforming the way production systems are built and run, driving improvements across three main dimensions of the digital transformation:

  • Dimension 1. Visibility into shop floor and field operations
  • Dimension 2. Visibility into the manufacturing supply chain
  • Dimension 3. Visibility into remote and outsourced operations.

In the subsequent sections, we’ll have a closer look at each of the digital transformation dimensions and explore them from the IIoT applications perspective.

Dimension 1. Visibility into the shop floor and field operations from the top floor

The Industrial IoT offers the revolutionary level of visibility into the shop floor and field operations, as well as the possibility of handy control over enterprise resources. IIoT technologies fill the gaps that lead systems like ERP and MES to come to their limits: the reliance on manual data input and the inability to work with detailed information (real-time equipment status records, inventory items’ location, etc.)

By providing manufacturers with second-by-second shop floor data, IIoT allows businesses to considerably increase manufacturing process productivity. IBM reports that using IIoT insights for manufacturing process optimization can lead up to 20% higher product count from the same production line.

The IoT applications that allow manufacturers to gain a higher level of vertical visibility fall into two groups:

  • Applications supporting manufacturing operations
  • Applications facilitating industrial asset management.

IoT-driven manufacturing operations

According to an IDC research, in 2016, IoT-enabled manufacturing operations accounted for a total spend of $102.5 billion, being the largest use case area across all industries. The researchers estimate that by 2025, the improvements in operations driven by IoT applications could be worth more than $470 billion per year. IoT applications for manufacturing deal with such operations as monitoring and optimizing equipment performance, production quality control, and human-to-machine interaction.

Monitoring equipment utilization

As ITIF research reports, IoT applications for monitoring machine utilization can increase manufacturing productivity by 10 to 25% and produce up to $1.8 trillion in global economic value by 2025. IoT solutions for monitoring machine utilization provide businesses with real-time equipment utilization metrics, thus offering a detailed view of what is occurring at every point of the production process.

Monitoring machine utilization starts with pulling relevant data about machine operating parameters, e.g., run time, actual operating speed, product output, etc., from sensors, SCADA or DCS systems. The data is gathered in real time and transmitted to the cloud for processing. The cloud aggregates the data and develops it into informative insights about equipment utilization KPIs (TEEP, OEE, setup and adjustment time, idling and minor stops, etc.). After the data is analyzed, the results are visualized and displayed to the factory workers via a user app (either web or mobile).

iot for machine utilization monitoring

BC Machining LLC, a North Carolina-based metal parts manufacturer, has deployed a machine utilization monitoring solution that helps the company to improve productivity and optimize the utilization of computer numerical control (CNC) machines. The IIoT solution uses real-time data from equipment sensors to provide reports on the machines’ cycle times, the number of parts produced, downtime, and more.

Product quality control based on condition monitoring

Monitoring the quality of the produced goods can be carried out in two ways: by inspecting a WIP (work in progress) as it moves through the production cycle or by monitoring the condition and calibration of machines on which a product is manufactured. Although quality control based on inspecting WIPs provides more accurate results (it helps to uncover minor defects, say, inaccuracies in parts alignment), there are certain limitations that hinder the method’s usage:

  • Quality control based on WIP inspection is applicable only for discrete manufacturing.
  • It is costly, time- and labor-intensive, as the WIPs are inspected manually.
  • It is rarely possible to inspect every WIP, therefore, the method provides a fractional view.

The second method, based on monitoring the condition and calibration of machines, offers less differentiation in terms of scope - it provides simple binary classification “good” and “not good”. However, it helps to detect bottlenecks in the manufacturing operations, identify badly tuned and/or underperforming machines, timely prevent machine damages, and more.

To monitor the quality of the production process, such parameters as equipment calibration, machine conditions (speed, vibration, etc.) and environmental conditions (temperature, humidity, etc.) are monitored to identify when they go beyond the normal thresholds. If sensor readings are approaching the thresholds that can lead to a potential product defect, a quality monitoring solution pinpoints the source of an issue, triggers an alert and recommends a mitigating action to fix or tune the machine and minimize the production of low-quality products.

Maastricht Mill, a Dutch paper producing company, has turned to IoT development to monitor the quality of produced paper. The enterprise rolled out the network of temperature and vibration sensors to monitor the condition of press rolls particularly critical for the quality of produced paper, which helped the company to minimize the amount of low-quality paper.

Product quality control based on condition monitoring

Monitoring safety

As the International Labor Organization reports, every 15 seconds, 151 workers have a work-related accident. Industrial IoT solutions for manufacturing help businesses address the safety issues and save $220 billion of annual injuries and illness costs.

In various industrial sectors, including mining, oil & gas, transport, etc., workers receive RFID tags that gather data on their location and wearable sensors collecting data about their heart rate, skin temperature, galvanic skin response, and other parameters. The sensor data is relayed to the cloud where it is analyzed against contextual data (e.g. from environmental sensors, legacy work planning systems, weather feeds, etc.) to detect unusual behavior patterns (say, sudden vertical movements, unusual heart rates, etc.), and prevent workers from falls, overexertion, and other injuries and timely report a safety threat.

For instance, a combination of high skin temperature, a raised heart rate, and no movement patterns for about a minute could indicate that a person suffers from overheating. Whenever such a situation is recognized, an IoT solution notifies an employee’s responsible person (a worker’s manager, a doctor, etc.) via a mobile application.

iot for safety monitoring

To ensure workers’ safety, Nation Waste, Inc. is leveraging a safety monitoring solution, powered by IBM’s Watson IoT. The solution uses a range of sensors, including accelerometers to measure workers’ movements and detect falls, heat sensors and heart rate measuring devices to help detect overheating and fatigue. Leveraging safety monitoring solutions, Nation Waste managed to reduce the number of workplace injuries and diminish their severity, not to mention the increase in profit margins by at least 40 percent.

IoT applications for industrial asset management

Along with improving the effectiveness of manufacturing operations, the Internet of Things is applied in manufacturing to ensure proper asset usage, extend equipment service life, improve reliability, and provide the best return on assets. The IoT applications facilitating industrial asset management include:

  • Industrial asset tracking
  • Inventory management
  • Predictive maintenance (based on condition monitoring).

It is estimated that the overall improvements arising from better asset management and maintenance could be worth more than $360 billion per year.

Industrial asset tracking

According to Zebra’s 2017 Manufacturing Vision Study, smart asset tracking solutions based on RFID and IoT are expected to overtake traditional, spreadsheet-based methods by 2022. By providing accurate real-time data about enterprise’s assets, their statuses, locations and movements, IoT-based asset management solutions remove the tracking burden from the employees (freeing up to 18 hours of monthly working time) and eliminate errors bound to the manual methods of data input.

To enable asset tracking for manufacturing, IoT works together with RFID. Each asset – be it a magnetic locator or a crane - gets labeled with an RFID tag, which serves as an asset identifier. Each tag has a unique ID, which is linked to the data about a particular asset. Both the ID and the corresponding asset data is stored in the cloud. The asset data may include the asset’s physical parameters, cost, serial number, model, assigned employee, area of use, etc. Once an asset, say, a crane, leaves an equipment storage yard, an RFID reader installed at the yard entrance, scans the tag attached to the crane and saves the record about the asset leaving the yard to an in-cloud database. Similarly, when the crane enters, say, a construction site, an RFID reader at the construction site entrance scans the tag and updates the data in the database. Logging such data throughout the asset’s journey allows technicians to see the movements of the assets.

iot for asset tracking

Along with that, GPS tracking can be used to state the location of the movable assets, for instance, machines used in construction. For movable items, asset tracking solutions are also used to calculate utilization. For instance, seeing for how long each movable (say, a bulldozer) is in use, technicians can pinpoint idling or underused machines and schedule preventive maintenance.

Construction company VerHalen Inc., for instance, turned to IoT development to implement a smart asset management solution. Now the employees can use a mobile app to see where all of their assets are located. Company’s managers can see how many tools and pieces of equipment are at a jobsite and who operates them. With real-time data on the tools’ usage and location, the enterprise has achieved a higher level of asset visibility and accountability, as well as saved its employees vast amounts of time previously spent on manual tracking and searching for the tools.

Enterprise inventory management

IoT-driven inventory management solutions help manufacturers automate inventory tracking and reporting, ensure constant visibility into the statuses and locations of individual inventory items, and optimize lead time (the time between an inventory order and its delivery). Due to these improvements, smart inventory management solutions are reported to save 20% to 50% of an enterprise’ inventory carrying costs.

Inventory management solutions applied in the manufacturing settings are based on IoT and RFID technologies. Each inventory item gets labeled with a passive RFID tag. Each tag has a unique ID that carries the data about the item the tag is attached to. To fetch the data from the tags, RFID readers are used. A reader catches tags’ IDs and relays them to the cloud for storing and processing. To establish the location and the movements of the scanned tags, along with the tags’ IDs, the data about the location of the RFID reader and the time of the reading are relayed to the cloud. The cloud pinpoints the location and the status of each item, visualizes the findings and displays them to the users.

Sekisui Alveo AG, a leading manufacturer of high-performance polyolefin foam materials implemented an inventory management solution based on RFID and IIoT. As the company produces finished foam products, they are labeled with RFID-tags. This makes it possible to view inventory levels in real-time, locate specific inventory items and automate inventory tracking processes that were previously handled manually.

Predictive maintenance, condition monitoring

According to Deloitte, predictive maintenance solutions based on the Industrial IoT are expected to reduce factory equipment maintenance costs by 40% and generate the economic value of $630 billion annually by 2025. The solution leads the IoT adoption – 55% of businesses are at least piloting predictive maintenance projects. This is how it is carried out from the technological perspective.

Predictive maintenance relies on the insights gained with continuous equipment condition monitoring. A piece of equipment gets sensors, which collect data on a wide range of parameters determining its health and performance, e.g. temperature, pressure, vibration frequency, etc.

Once collected, the real-time data from multiple sensors is transmitted to the cloud, where sensor readings are combined with metadata (equipment’s model, configuration, operational settings, etc.), equipment usage history, and maintenance data fetched from ERP, maintenance systems and other sources. The whole of data is analyzed, visualized, and presented to shop floor workers on a dashboard or in a mobile app.

However, mere reporting and visualization is still far from prediction. To enable prediction, the combined data set is run through machine learning algorithms to pinpoint abnormal patterns that may lead to equipment failures.

Data scientists use the recognized data patterns as the basis for creating predictive models. The models are trained, tested, and then used to identify whether any incipient problems take place, predict when a machine is likely to fail, pinpoint operating conditions and machine usage patterns that lead to failures, etc.

For instance, machine’s condition parameters (e.g., temperature, vibration, etc.), operating parameters (e.g., speed, pressure, etc.), and environmental parameters (e.g., humidity, temperature, etc.) are within normal thresholds. However, combining these parameters and analyzing the joined data set against predictive models helps to reveal that the combination of parameters normal when taken separately can cause, say, a machine’s engine failure. Once a potential failure is identified, the predictive maintenance solution sends a notification to the maintenance specialists, notifying them of potential degradation and recommends a mitigating action.

iot for predictive maintenance

VR group – a railway company in Finland – has implemented an IIoT-enabled predictive maintenance solution to improve the reliability of the carriages and avoid excessive maintenance activities. They use data from sensors attached to the potential fault points (roller axle bearings, brake disks, etc.) to gain real-time insights into the condition of the rails and rolling stock and identify root causes of incipient failures.

Dimension 2. Visibility across the manufacturing supply chain

Currently, for 52% of supply chain managers, end-to-end supply chain visibility still seems far-off. However, the prognoses for the adoption of IoT-driven manufacturing supply chain management solutions are quite optimistic: As IDC predicts, by 2020, 80% of supply chain interactions are expected to happen across cloud-based networks. The same source states that the transition towards smart, IoT-enabled supply chain management solutions is predicted to drive supply chain productivity by 15% and increase cost efficiency by 10%.

Smart supply chain management solutions provide manufacturers with real-time insights into the location, status, and condition of every object (be it an individual inventory item on a warehouse shelve or a truck delivering supplies) at any segment of the manufacturing supply chain.

An even bigger value of IoT applied for the manufacturing supply chain optimization is that it enables the shift from knowing whether a particular SKU is available to knowing the status of each item of that SKU.

For instance, with the traditional supply chain management methods, the manufacturers could only get general data about the availability of an SKU:

1,435 items of SKU X are in warehouse 3.

With IoT in the manufacturing supply chain, enterprises get the data about both the location and the properties (e.g. production date, shelf life, etc.) of each individual item of the SKU. For instance:

1,435 items of SKU X are in warehouse 3, of those:

  • 1,000 items were produced 12 days ago.
  • 435 items were produced 22 days ago.

Along with monitoring the location and the properties of the objects, IoT is applied to monitor the conditions, under which the objects are stored and delivered. Before IoT came into play, the condition of goods could only be monitored once they arrived at the delivery point. Now, the condition of materials, components and goods can be monitored en route, which is especially relevant for the manufacturers of breakable and perishable items (e.g. pharmaceuticals, food, glassware, modern nanomaterials, etc.).

Consider an example of a pharmaceutical company shipping an order to a distribution center via a third-party logistics service provider. Sensors attached to the containers monitor the temperature inside the containers. Suppose, because of a cooling system failure, the temperature inside the containers is starting to rise. A temperature sensor attached to the inner side of the container ‘detects’ the deviation from the recommended threshold. The IoT solution notifies the manufacturer that the delivery conditions have been violated and alerts the driver, who resets the cooling system, thus, preventing spoilage of the transported medicines.

iot for supply chain management

Dimension 3. Visibility into remote and outsourced operations

High logistics costs, increasing demand for customization, the complexity of the global supply chain, and the lack of local talent (hence, the need to outsource) demand the shop floor operations to get distributed.

When an enterprise builds or buys a manufacturing facility in a different city, state or country it still has to maintain its manufacturing and production standards (material testing, industrial automation, predictive maintenance, and other). Impossible to be monitored with traditional methods, the compliance with the production standards can be monitored with IoT.

For instance, IoT-based predictive maintenance and timely prediction of potential failures allows scheduling maintenance activities in advance and eliminates the need to keep a local maintenance team. Similarly, IoT-driven utilization monitoring solutions help manufacturers keep an eye on the efficiency of manufacturing operations (by providing real-time equipment efficiency metrics) without direct access to the shop floor.

Another example of how IoT promotes distributed operations is industrial smart, connected products (SCPs). Smart, connected products are complex systems comprising hardware, sensors, connectivity, embedded intelligence, and cloud software.

For example, industrial smart, connected products located at a manufacturing affiliate in Texas enable enterprise managers, say, in California access real-time data about a wide range of the SCPs’ operating (e.g., changes in the temperature of transponders, critically high rotation speed of a milling machine’s spindles, etc.) and condition (e.g., temperature, vibration, etc.) parameters. The managers are informed about possible overload conditions and breakages, as well as violations of the standard operating procedures.

Visibility into remote and outsourced operations

Equal opportunities for small and medium-sized enterprises

By driving improvements in the business and manufacturing processes, IoT provides equal transformational opportunities for small and medium-sized enterprises.
For instance, similar to a large company having several affiliates in the USA and in Mexico, a medium-sized enterprise with the affiliates in Illinois and Texas is geographically distributed, hence, faces similar challenges of distributed manufacturing. Due to reliance on cloud computing and universal, often open-source software, IoT makes digital transformation possible for SMEs.

For instance, an injection molding company with just 50 employees has implemented an IoT-based condition monitoring solution that allows the company to watch over the health and performance of industrial robots. The solution monitors the condition of industrial machines and alerts technicians if a machine is likely to fail. This allows the company to predict potential equipment failures and timely mitigate them to carry out a 24/7 production. This proves that with flexibility and visibility IoT provides, SMEs may outcompete large enterprises if those delay digital transformation and rely on economy of scale only.

The challenges of IIoT adoption

According to a BCG survey (2016), the toughest challenges US enterprises face starting IoT-enabled digital transformation initiatives include uncertainty about the ROI, data security and privacy issues, the lack of qualified employees, and the integration with the legacy systems. Other significant concerns include the inability to do fast experiments, and missing IoT standards. Let’s look into the key challenges:

  • Large investment needs and uncertainty about the ROI. IoT initiatives incur several investments categories, including spending on hardware (sensors, gateways), connectivity, cloud storage, administrative labor, technical support, and more. Businesses also have to consider how quickly they can roll out new solutions and how fast it will take for a solution to start generating revenue.
  • Data security issues. 58% of IIoT adopters believe IIoT is increasing the risk of cyberattacks (however, half of IoT adopters claim that they do not have a plan to prevent losses from possible security threats). Verizon’s 2017 Data Breach Investigations Report confirmed 1,935 data breaches and 42,068 incidents. It found that no business or industry is 100% secure when it comes to the compromise of data. As IoT devices become more commonplace, the number of IoT security threats is expected to rise. Gartner predicts that 25% of attacks will involve IoT, while the spending on IoT security will reach $547 million.
  • Lack of qualified employees. Inmarsat found that 72% of businesses around the world have a shortage of people at the management level with experience in IoT deployment. Another 80% report a lack of skills among employees in IoT deployment. Another research found the specific skills that are lacking, which include analytics expertise and experience in big data, embedded software development, embedded electronics, IT security and artificial intelligence. This leaves businesses unable to take advantage of the potential that IoT solutions offer.
  • The integration with operational technologies and legacy systems. The difficult part of rolling out an IoT solution in the manufacturing ecosystem is securely integrating IT and OT without data losses and security inconsistencies. Ensuring seamless convergence between IT and OT is difficult because in the past, the systems had different objectives, hence, were build based on different technologies and networks. Today, the rapid adoption of Ethernet protocols at the machine level and fast diffusion of web-based user interfaces are gradually easing the integration process, but the challenge is still to be solved.

To wrap it up

The Industrial IoT helps manufacturing enterprises to maximize productivity through maintaining production uptime, reducing costs and eliminating waste. Leveraging IoT data, manufacturers get a better understanding of the manufacturing and supply chain processes, improve demand forecasting, achieve faster time to market, and enhance customer experience. However, considering the scale and the complexity of the Industrial IoT initiatives, successful IIoT adoption requires thoughtful orchestration throughout the IIoT application design and execution segments.
